WebUI

Purpose

The EAA WebUI is a lightweight standalone browser interface for watching agent progress and sending user input. The task-manager process owns the agent runtime API; the WebUI process serves the browser app and proxies browser API calls to that runtime over HTTP.

Launch pattern

Configure the task manager with separate checkpoint and transcript databases, then start its runtime server explicitly:

task_manager = BaseTaskManager(
    ...,
    checkpoint_db_path="checkpoint.sqlite",
    transcript_db_path="transcript.sqlite",
    use_webui=True,
)
task_manager.start_webui_runtime()
task_manager.run_conversation()

In a separate process, start the browser-facing WebUI and point it at the local runtime URL. The browser only needs to reach the WebUI server; runtime API calls are proxied by the WebUI process.

from eaa_core.gui.html import run_html_webui

run_html_webui(
    "http://127.0.0.1:8010",
    host="127.0.0.1",
    port=8008,
)

To launch the WebUI without blocking the current Python process, use the subprocess launcher:

from eaa_core.gui.html import launch_html_webui_subprocess

process = launch_html_webui_subprocess(
    "http://127.0.0.1:8010",
    host="127.0.0.1",
    port=8008,
)

# Later, when the UI is no longer needed:
process.terminate()

Runtime API

The agent-side runtime exposes:

  • GET /api/state for initial state and reconnect recovery
  • GET /api/events for Server-Sent Events
  • POST /api/input for ordered user input
  • POST /api/interrupt for cooperative interruption
  • POST /api/approval for tool approval decisions
  • GET /api/skill-catalog for available skill metadata
  • GET /api/image and POST /api/upload-image for image display and upload

The browser calls these routes on the WebUI origin. The WebUI server forwards them to the configured runtime URL, so the runtime can remain bound to 127.0.0.1 while the WebUI binds to a remote-accessible interface.

Persistence

checkpoint_db_path stores LangGraph checkpoints only. transcript_db_path stores the agent-owned durable transcript log. The WebUI does not read this database for message transport or initial state. Browser-visible messages, commands, approvals, interrupts, and runtime status are held by the task-manager-owned runtime controller, not by SQLite relay tables.

Extending the WebUI

Task-specific packages can subclass HTMLWebUIBase and override page_html(), styles(), script(), or build_app() while keeping the same runtime API contract:

from eaa_core.gui.html import HTMLWebUIBase


class FocusingWebUI(HTMLWebUIBase):
    def styles(self) -> str:
        return super().styles() + "<style>.eaa-title::after { content: ' focusing'; }</style>"


FocusingWebUI("http://127.0.0.1:8010").run(host="127.0.0.1", port=8008)
